Product Features
1.Weichai WP10G178E355 engine has sufficient power, which is easy to maintain, has the advantages of high combustion efficiency, and meets the national III emission standard.
2.Planetary power shift, forced lubrication gearbox and hydraulic power assisted steering system make the machine easy to operate, with high power transmission and high production efficiency.
3.Closed system can keep the water tank pressure at a specific value, which can improve the evaporation temperature and heat dissipation efficiency of cooling water. The fan power comes from the engine, and the forced air supply can increase the cooling effect.
4.The mainstream 14MPa working hydraulic system has stable operation and overload protection function, which can greatly reduce the failure rate of hydraulic components.
5.The use of waterproof connectors, new relays and integral injection molded instrument panel of the whole vehicle can effectively avoid electrical system failures. The instrument box integrates air conditioning, electrical appliances and instruments, making it more beautiful and high-end.
6.The main frame of the full box type structure adopts the steel plate welded full box type integral structure, which is welded with the rear axle box as a whole. It has a high capacity to bear impact loads and resist bending and torsion. High quality welds ensure that the main frame has a full life cycle.
7.The swing type of the splay beam and the suspension structure of the balance beam, which connect the rack and the walking system, can transfer the working load and impact load during operation to the main frame, effectively improving the stability during operation under complex working conditions.
8.The standard straight tilt bulldozer has a strong cutting force and a three tooth scarifier, which can be used to loosen clay, hardened frozen soil and other soil layers, and has high efficiency and super penetration.
Technical Parameters
|
Model |
HD16 |
|
Dimension (mm) |
4990×3440×3110 |
|
Weight (T) |
16.4 |
|
Engine model |
WP10G178E355/WD10G178E25 |
|
Power (kw/r/min) |
131/1850 |
|
Minimum fuel consumption g/KW. h |
214 |
|
Grounding length (mm) |
2430 |
|
Ground specific pressure (MPa) |
0.066 |
|
Minimum ground clearance (mm) |
405 |
|
Gradeability (°) |
30 |
|
No. of track shoes (each side) |
37 |
|
Width of Track shoe (mm) |
510(560.610) |
|
Track Gauge (mm) |
1880 |
|
pitch (mm) |
203.2 |
|
No of carrier rollers (each side) |
2 |
|
No. of Track roller (each side) |
6 |
|
Maximum traction force (KN) |
144 |
|
Blade type |
Straight-tilt Blade |
|
Blade length x height (mm) |
3440×1150 |
|
Blade Capacity( m3 ) |
Straight-tilt Blade:4.5 |
|
Blade lift height(mm) |
1095 |
|
Blade depth (mm) |
540 |
|
Maximum inclination of blade (mm) |
400 |
|
Forward (km/h) |
F1:0 〜 3.29 |
|
F2:0 〜 5.82 |
|
|
F3:0 〜 9.63 |
|
|
Reverse (km/h) |
R1:0 〜 4.28 |
|
|
R2:0 〜 7.59 |
|
|
R3:0 〜 12.53 |
|
Coolant capacity (L) |
79 |
|
Fuel tank capacity (L) |
300 |
|
Engine oil capacity (L) |
19 |
