| Model | BLTB-140 | ||
| Parameter | |||
| Weight | Side | kg | 1855 |
| lb | 4090 | ||
| Length | Side | mm | 2411 |
| inch | 94.9 | ||
| Working Oil Flow | l/min | 120-180 | |
| gal/min | 31.7-47.6 | ||
| Set Pressure | bar | 210 | |
| psi | 3046 | ||
| Working Pressure | bar | 160-180 | |
| psi | 2321-2611 | ||
| Impact Rate | bpm | 350-500 | |
| Hose Diameter | inch | 1 | |
| Chisel Diameter | mm | 140 | |
| inch | 5.5 | ||
| Chisel Length | mm | 1250 | |
| inch | 49.2 | ||
| N2 Pressure(Backhead) | bar | 14-17 | |
| psi | 203-247 | ||
| N2 Pressure(Accumulator) | bar | 55-60 | |
| psi | 798-870 | ||
| Noise 85dB(A)-Distance | m | 16-22 | |
| Applicable Excavator | t | 20-24 | |
|
Brand |
Model |
|
CAT |
219 320 322 325 320C |
|
KOMATSU |
PC200 PC220 |
|
DOOSAN DAEWOO |
DH220 DH225 DH258 |
|
HYNUDAI |
R220 R205-7 R225 |
|
HITACHI |
ZX210 ZX220 ZX230 ZX240 ZX270 |
|
KOBELCO |
SK220 SK230 SK250 |
|
VOLVO |
EC210 EC240 |
|
SANY |
SY185C-8 SY195C-9 SY205C-9 SY215C-9 SY225C-9 SY235C-9 |
|
LIUGONG |
CLG210 CLG230 CLG920 CLG923 CLG925 |
|
STRONG |
JCM924D JCM922D JCM921D GC228LC-8 GC208-8 GC258LC-8 |
|
LINGONG |
LG6210E LG6225E LG6250E |
|
FOTON |
230 240 260 |
|
XGMA |
230LC-7B 240LC-8 |
|
SUNWARD |
SWE230 |
|
ZOOMLION |
ZE205E ZE210E ZE230E ZE260E |
|
XCMG |
220 240 250 |
