| Model | BLTB-125 | ||
| Parameter | |||
| Weight | Side | kg | 1366 |
| lb | 3012 | ||
| Length | Side | mm | 2236 |
| inch | 88.0 | ||
| Working Oil Flow | l/min | 90-120 | |
| gal/min | 23.8-31.7 | ||
| Set Pressure | bar | 210 | |
| psi | 3046 | ||
| Working Pressure | bar | 150-170 | |
| psi | 2176-2466 | ||
| Impact Rate | bpm | 350-650 | |
| Hose Diameter | inch | 1 | |
| Chisel Diameter | mm | 125 | |
| inch | 4.9 | ||
| Chisel Length | mm | 1100 | |
| inch | 43.3 | ||
| N2 Pressure(Backhead) | bar | 14-17 | |
| psi | 203-247 | ||
| N2 Pressure(Accumulator) | bar | 55-60 | |
| psi | 798-870 | ||
| Noise 85dB(A)-Distance | m | 10-18 | |
| Applicable Excavator | t | 14-18 | |
|
Brand |
Model |
|
CAT |
315DL |
|
KOMATSU |
PC150 PW150 PW170 |
|
DOOSAN DAEWOO |
SOLAR170 DH170 |
|
HYNUDAI |
ROBEX170W ROBEX180LC |
|
VOLVO |
EC140B/150 EW150/160 |
|
STRONG |
GC178-8 |
|
FOTON |
170 |
|
SUNWARD |
SWE150 |
