Product Features
1. It is equipped with full-automatic drill rod fixture system for connection and disconnection, which is convenient for one-man operation.
2. It is equipped with aluminium alloy guide and lightweight design, which makes drilling more efficient and stable.
3. It is equipped with imported electrical element free from dust and water, which makes drill rig meet severe mine environment requirements.
4. It is equipped with single-stage efficient screw compressor which is stable and durable.
5. It is equipped with EATON rotation motor which is more durable and stable.
6. It is equipped with extra-large maintenance space, which makes wearing parts replacement easier.
7. It is equipped with two-stage air filter, which makes it meet severe mine environment requirements.
Technical Specifications
|
Engine
|
Yuchai 162Kw
|
|
Hole diameter
|
90-115mm
|
|
Drill storage bunker
|
6+1 (60 drill rods)
|
|
Guide
|
Aluminium alloy Guide
|
|
Rotary torque
|
1700N.M (13Mpa)
|
|
Rotary Speed
|
0-120r/min
|
|
Feed beam stroke
|
3400mm
|
|
Tramming speed
|
Max. 3km/h, min. 1.5km/h
|
|
Tramming type
|
Cylinder+steel wire rope
|
|
Compressor
|
BAOSI double-stage: 14m³,16KG
|
|
Total Weight
|
10,000KG
|
|
Overall dimension
|
8800x2300x2600mm
|
