Product Features
1. It is equipped with full-automatic drill rod fixture system for connection and disconnection, which is convenient for one-man operation.
2. It is equipped with aluminium alloy guide and lightweight design, which makes drilling more efficient and stable.
3. It is equipped with imported electrical element free from dust and water, which makes drill rig meet severe mine environment requirements.
4. It is equipped with single-stage efficient screw compressor which is stable and durable.
5. It is equipped with EATON rotation motor which is more durable and stable.
6. It is equipped with 14-core dust removal air filter with large filtering area, which can meet 90-115 hole diameter requirements
7. It is equipped with extra-large maintenance space, which makes wearing parts replacement easier.
8. It is equipped with two-stage air filter, which makes it meet severe mine environment requirements.
Technical Specifications
|
Engine
|
Yuchai 176Kw
|
|
Hole diameter
|
90-115mm
|
|
Drill storage bunker
|
6+1 (3m drill rod)
|
|
Guide
|
Aluminium alloy Guide
|
|
Valve
|
Qiangtian
|
|
Rotary torque
|
1700N.M (13Mpa)
|
|
Rotary Speed
|
0-150r/min
|
|
Rotation motor
|
Eaton 6K Series
|
|
Tramming speed
|
Max. 3km/h, min. 1.5km/h
|
|
Tramming type
|
Aluminium alloy guide+cylinder
|
|
Compressor
|
BAOSI double-stage: 15m³,18Bar
|
|
Total Weight
|
12,000KG
|
|
Electric system
|
Imported electrical element, IP56 grade dust prevention and water prevention
|
