| Basic Parameters | |
| Length | 15620mm |
| Width | 2500mm |
| Height | 2638mm |
| Weight | 29400Kg |
| Wheel Base | 4000mm |
| Ground Clearance | 463mm |
| Grade Alibility | 14° |
| Travelling Speed | 0-15km/h |
| Hydraulic Drifter | |
| Model | RC2000 |
| Shank Adapter | R38 T38 |
| Impact Power | 18Kw |
| Impact Rate | 60Hz |
| Impact Pressure | 210 bar |
| Rotation System | Seperate rotation |
| Rotation Speed | 150-250 rpm |
| Max. Rotation Torque | 590 N.M |
| Rotation Pressure | 0-170 bar |
| Sound Level | 105 dB(A) |
| Feed | |
| Model | FDH2038 |
| Feed Type | Cylinder-steel wire rope |
| Drill Steel Length | 3700mm |
| Feed Force | 15-25 kN |
| Hole Depth | 3370mm |
| Boom | |
| Model | CYTJ45/2 |
| Feed Compensation | 1250mm |
| Parallel Holding | Complete |
| Feed Roll-over | ±180° |
| Feed Lifting Angle | ﹢95°/－10° |
| Boom Lifting Angle | ﹢53°/－30° |
| Max. Boom Swinging Angle | ±35° |
| Hydraulic System |
|
|
Hydraulic Pump Units |
1 variable pump for impacting / positioning; 1 constant pump for drifter rotation |
|
Max. System Pressure |
230 bar |
|
Max. Hydraulic Oil Tank Volume |
265L |
|
Low Oil Level Indicator |
|
|
Hydraulic Oil Cooler |
Water Cooled |
|
Hydraulic Filter Indicator |
|
|
Operation Panel |
|
|
Oiling Pump |
|
|
Air System |
|
|
Compressor Power |
11Kw |
|
Compressor Capacity, Max. at 0.7MPa |
25l/s |
|
Air Pressure Gauge |
|
|
Water System |
|
|
Water Booster Pump |
CDL8-16 |
|
Max. Capacity |
160L/min |
|
Min. Water Inlet Pressure |
2 bar |
|
Water Pressure Gauge |
|
|
Electrical System |
|
|
Total Installed Power |
123Kw |
|
Main Motors |
55+55Kw |
|
Voltage |
380/1000V |
|
Tramming Light |
24VDC/40W, 20W; 220VAC/50W |
|
Central Lubrication System |
|
|
Grade Ability |
14° |
|
Fire Extinguisher |
|
|
Horn, Beacon and Reverse Alarm |
|
